cont. cutter pinless 2-up K996 + K971 feeder, 4 enclosures, Kern unwinder DR6

Images:

 Configuration:
TWIN channel cont.+cut sheet, 4 enclosures, cognex reading on all channels above for 2D Datamatrix

Envelope sizes:
DL, C6, C6/5, C5

Speed in env/h:
24.000 gross

1st channel:
Kern DR6 unwinder, K996 cutter continuous pinless, reading: 4x Datamatrix (Cognex) 2x from above and 2x from beneath
https://youtube.com/shorts/_3WmWE0yEB8?feature=share

2nd channel:
K971 feeder with 1x Cognex for Datatmatrix (complete channel presently unused) with VSK

Enclosures:
4 1x ZSEG/1xZSMS/ for 4 stations in total

Number of check bins:
2

Extras (included):
Vertical stacker, conveyor
Kern DR6-S-150 unwinder with 70mm core, right version Y2007
envelope reading on exit (comparison)

Option (not included):
OMR reading from above AND beneath (4 read heads)
unwinder Lasermax LX550 or Hunkeler UW6 150 VU R 7183
cutter/merger PINFED K940/990 with omr
1/6" double cut
2/6" double cut

Frequency:
50 Hz.

1^st Installation:
2011

Clicks/envelopes in Mio:
app. 24 Mio on counter, definitely higher

Status:
installed at customer's site, viewing possible

Availability / ex works:
September 25 / EU

Price in EURO:
Request a quote

video:
https://youtube.com/shorts/2nRKORQ7IAo?feature=share

manufacturer's brochure:
the K3500 Silverline was designed to meet customer demands for shorter production times, maximum flexibility and the
latest automation. The K3500 Silverline inserting system is Kern’s flagship system and your gateway to high speed. Able to
process pre-cut single sheets as well as continuous forms from fanfold stacks. The K3500 adjusts to the application
being run and can produce up to 24,000 mailpieces per hour. Combined with the Dual Channel VSK module and
the K999s high speed cutting system, the K3500 can maintain full rated speed at up to 8 pages per envelope.

machine's layout:

ref. nr:
krn3525
