Hunkeler roll 2 stack w CS6-1, 4-up, 150m (20) SOLD

complete Hunkeler line w CS6-1 for 4-up
150m, pinless + Option Horizon folder

Images:

Manufacturer / Model:
Hunkeler  / CS6 - 1, single cut, 3x slit knife + side trimmers

line consists of the following modules:
unwinder UW6 VU 150m
webbuffer WB6
cutter CS 6-1 7184 cutter pinless, for 4-up, 150m/min,
stacker LS6 7191
conveyor TB6 2m

webwidth:                330mm - 520mm (13"-20,5")
paperweight:           60 - 30gsm
doc length (stack): 140mm - 355mm, single doc 203mm - 1.574mm
Transport:                pinless
Speed in m/min:      up to app. 150m/min

Extras (included):
airshaft for UW6
cognex reading from above

Option (not included):
TS6 transfer station

Horizon DIF-56 feeder (for stand alone use) or single sheet transfer from Hunkeler
Horizon AF 566-T4F (2 folding units for crossfold)

folding unit 1:
Horizon AF 566F main folding unit with feeder and 6 pockets
3 knife shafts (Messerwelle) for:
- longitudinal perforation
- slit cut
- chip out
- cease

folding unit 2:
Horizon T-564F add. folding unit with 4 pockets
1 knife shaft for:
- slit knife
- chip out

TRESU Coater (never used)



LI4 interface
weko rfdi moisturizer
Loop control Type: LC6-S 7188, YOM 2018
external vacuum unit VU6-800 or VU6-1200
WM6 UNEVEN 71 or EVEN

180 degree floor turn station

Frequency:
50 Hz and 60Hz (works also e.g. in the US)

1^st Installation:
2018

Mileage:
1.280h, app. 15mio cuts

Status:
still installed (testing possible)

Availability / ex works:
imm / EU

Price in EURO:
Request a quote

manufacturers brochure:
click here

machine's layout:

p2p_ID:
hu_cs6_20

video:
